Product Information
Overview
The Oil Tray Rack features a specially engineered slanted tray system that ensures cooking oil bottles and other large liquid containers are displayed safely, neatly, and attractively. The angled presentation prevents tipping while making labels clearly visible, solving a common challenge in grocery merchandising.
Built with strong mild steel, adjustable components, guard rails, and tray end stoppers, it provides excellent stability, spill protection, and ease of restocking. The robust construction handles high-volume traffic while maintaining a clean and professional look.
A practical and intelligent choice for supermarkets and hypermarkets, the Oil Tray Rack improves safety and visual standards for heavy liquid products, reduces operational hassle, and helps create a more organized and customer-friendly grocery section.
Features
Data Strips
Integrated data strips allow clear and consistent price labeling across shelves. They make it easy to update product information while maintaining a neat and professional display.
Tray End Stoppers
Tray end stoppers help prevent products from slipping or falling off the shelves. They improve product safety while keeping items neatly aligned for better visibility.
Guard Rails
Guard rails provide additional support for displayed products, especially in high-traffic areas. They help keep items securely in place while enhancing overall shelf organization.
Level Adjustable Nuts
Level adjustable nuts ensure the rack remains stable even on uneven flooring. This allows for easy installation and consistent alignment across the entire display system.
Adjustable Shelving
Adjustable shelving allows flexible configuration to accommodate products of different sizes. It enables efficient space utilization and easy adaptation to changing display needs.
Strong mild steel construction for reliable everyday use
Data strips for easy product labelling and identification
Guard rails or wire mesh barriers for safety and product protection
Multiple shelf sizes to support different product categories
Tray end stopper and bottom cover for added practicality
Detachable leg base with level adjustable nuts for better floor adjustment
Powder-coated and oven-baked finish for improved durability
Specifications
|
Material |
Mild Steel (MS) |
|
Bracket Thickness |
2.5 mm |
|
Leg Thickness |
1.6 mm |
|
Shelf Thickness |
1.0 mm |
|
Backsheet Thickness |
0.8 mm |
|
Number of Shelves |
Fully Customizable Minimum - 1 Maximum - 12 |
|
Configurable Shelf Depth |
18" inches 15" inches 12" inches |
|
Additional Components |
Data Strips / Label Holders Guard Rails / Wire Mesh Barriers Tray End Stopper Bottom Cover Detachable Leg Base Level Adjustable Nuts |
|
Load Capacity |
Not less than 50 kg per shelf |
Dimensions
|
Height |
Customizable Maximum - 12 feet |
|
Width |
Customizable Based on store layout |
|
Depth |
Customizable Based on number of shelves Supported Sizes: 18" inches 15" inches 12" inches |
Finish
|
Surface |
Fully powder coated |
|
Process |
180°C oven-baked coating for durability |
Powder Coating Color Options
Most racks are supplied in a two-color combination. The main body including brackets, pillars, legs, and structural members is finished in the Main Colour , while the backsheet, shelves, and other selected parts are finished in the Combination Colour .
We support mix-and-match combinations from both color groups to suit your store branding and interior theme.
Main Colour
Premium White
11-21-372
Super Ivory
11-21-385
Graphite Grey
11-21-417
Black
11-21-004
Combination Colour
Pure Orange
11-21-092
PO Red
11-21-003
Signal Yellow
11-21-036
Yellow Green
11-21-124
Pepsi Blue
11-21-052
Note: Shades shown on screen are indicative only. Actual powder coating shades may vary slightly from digital display and should be confirmed against the physical shade card.
